KP35 TURBO 2003- Renault, Nissan 54359880002
Availability:
13 in stock, ready to be shipped
Original price
$ 8,000.00
-
Original price
$ 8,000.00
Original price
$ 8,000.00
$ 8,000.00
-
$ 8,000.00
Current price
$ 8,000.00
| Part Number | 54359880002 |
| Previous version | 5435-988-0002, 54359880000, 5435988 0002, 54359550002 |
| OE Number | 14411BN700, 14411-BN700, 14411-00QAG, 1441100QAG, 14411BN701, 14411-BN701, 8200119854, 8200189536, 8200351471, 8200409037, 8200409838, 820057 |
| Year | 2003- |
| Description | RENAULT Clio, Kangoo, Megane II, NISSAN Almera, Micra |
| Manufacturer Part Number | 54359700002, 54359700000, 54359710002, 5435-970-0002, 5435-970-0000, 5435-971-0002 |
| CHRA | 54357100500 (5435-710-0500) (1303035901, 1000030013) |
| Turbo Model | KP35-1672CBA240.82ACAXD |
| Engine | K9K-702, K9K-260 |
| Engine Manufacturer | Nissan |
| Offset | 1.5L, 1460cc, 4 cylinders |
| KW | 59/60 hp |
| Max RPM | 4000 |
| Gasoline | Diesel |
| Comparison number | 7701473122, 8200409037, 8200351471, 8200189536, 8200119854 |
| Angle α (compressor housing) | 271º |
| Angle β (turbine casing) | 292º |
| Bearing housing | 54391510010 (54391510008, 54391510002) (oil cooled) (1303035450, 1900011005) |
| Turbine wheel | 54351208500 (54351205015, 54351205006) (Ind. 34.7mm, Exd. 29.2mm, Trm 5.46, 9 Blades) (1303035435, 1100011009) |
| Comp. Wheel | 54391232001 (54311285002) (Ind.29.5 mm, Exd.41 mm, Trm 4.2, 5 + 5 blades, flat back) (1303035400, 1200011008) |
| Back plate | 54391523000 (54391503001) (1303035301, 1800016006) |
| Heat shield number | 54351652000 (1303035340, 2030016006) |
| Repair Kit | Main set, service (5000040032) |
| Turbine housing | 54351009025 |
| Compressor cover | 54351015028 |
| AR turbine housing | 240 |
| Solenoid | 58201104182 (1303035380, 2061016028) |
| Gasket (turbine inlet) | 210598 |
| Gasket (turbine outlet) | 210599 |
| Gasket (oil outlet) | 210553 (Paper) |
| Gasket kit | (2090505265) |
| Manufacturer | Borg Warner - 3K - Schwitzer |
Interchangeable with 54359880000
Applications
2001- Renault Megane II 1.5L dCi Engine K9K-702
2001- Renault Kangoo I 1.5L dCi Engine K9K-702
2001-05 Renault Clio II 1.5L dCi Engine K9K-702
2001 - Nissan Micra 1.5L dCi K9K-260 Engine
2001 - Nissan Almera 1.5L dCi K9K-260 Engine
